Product Name

SILENT HI-POWER CZ4A 4B11 EVO10

MSRP

$1,380.00


Specifications

Product Code
31019-AM010
WEIGHT(kg)
21
NO. OF BOX
1
LENGTH (mm)
1850
WIDTH (mm)
500
HEIGHT (mm)
500

Available for


Make
MITSUBISHI
Model
LANCER EVOLUTION
Years
2008-2016
Engine
4B11
Chassis
CZ4A
Drive Train
AWD

Remarks

For grade "GSR" "RS" and 300ps model.



HKS

Cert. No.JARI30090004
VehicleLANCER EVOLUTION
ModelCZ4A(X)
Engine4B11(TURBO)
Model Year07/10 - 15/07
Shape of mufflerHP S(Curl)
(silent Hi-Power)
Main materialS304(*2)
Diameter of tip94 L&R
Diameter of center pipe65-50.8 x 2(*3)
Close noise levelStockL83 R84
HKSL91 R92
About road clearance(*4)Clearance125mm
Portion of the kitCenter pipe
Remarks
Product Weight







Remarks

For grade "GSR" "RS" and 300ps model.



About HKS muffler

*1: About silencer shell type of Silent Hi-Power
TYPE-S/Oval silencer for noise reduction.
TYPE-H/Round silencer for performance.

*2: Main material in the component figure.

: SUS304/High quality stainless steel.
: SUH409/Stainless steel commonly used for stock exhaust.

*3: About center pipe
Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension.

*4: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle.
The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit.

Caution: Hook, bracket, stay may be changed without prior notice.

★ Exhaust noise level at idle.
