Product Name

LEGAMAX PREMIUM FORESTER SJG FA20T/C

MSRP

$1,820.00


Specifications

Product Code
31021-AF023
WEIGHT(kg)
30.05
NO. OF BOX
1
LENGTH (mm)
1520
WIDTH (mm)
620
HEIGHT (mm)
620

Available for


Make
SUBARU
Model
FORESTER 2.0 XT
Years
2014-2018
Engine
FA20
Chassis
Drive Train
AWD

Remarks

with center pipe.Not fit to stock rear bumper skirt.



HKS

Cert. No.JQR40134011
VehicleFORESTER
ModelSJG
EngineFA20(TURBO)
Model Year12/11 - 18/06
Shape of mufflerRS (LEGAMAX Premium)
Main materialS304(*2)
Diameter of tip100 L&R
Diameter of center pipe65 - 54 x 2(*3)
Close noise levelStock74
HKS78
About road clearance(*4)Clearance215mm
Portion of the kitCenter pipe
Remarks
Product Weight







Remarks

with center pipe.Not fit to stock rear bumper skirt.



About HKS muffler

*1: About silencer shell type of Silent Hi-Power
TYPE-S/Oval silencer for noise reduction.
TYPE-H/Round silencer for performance.

*2: Main material in the component figure.

: SUS304/High quality stainless steel.
: SUH409/Stainless steel commonly used for stock exhaust.

*3: About center pipe
Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension.

*4: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle.
The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit.

Caution: Hook, bracket, stay may be changed without prior notice.

★ Exhaust noise level at idle.
